Second Hand PCB Circuit Board Etching Machine

We offer services of machine operation training, making sure the machine is be renewed like new machine, parts replacement arrangements, operation consulting, etc.

Specifications:
Product name: second hand etching machine
Power: 11.5KW/380V/50HZ
Working width: 650mm
Etching area: 650*L (not limited)
Etched type: Double Spraying & Swing
Swing system: Oscillate Nozzles
Working Temperature: 37~45°C
Heat System: Titanium, 3KW
Cool System: PE cooling Pipe, 25 meter
Machine Size: 14550*1500*1450mm
Weight: About 6000kgs
Process: enter ---etching --- rinse --- stripping ---- rine --- drying---- out

Automatic Control System:
Speed adjust system Pressure Adjust System Temperature control system
High temperatures resist (0~100°C)German PP material
Double Net Filter System  Long times Etching Ability

Introduction:
This double etching machine can do good etching works of metal plate.
It's mainly used to etch through the metal decoration plates, nameplates, signs, copper washers, gasket, encoder, TV shadow, stencils gobos, metal models, SMT, metal crafts and so on.
Materials can be Steel, Stainless steel, Copper, Brass, Aluminum, titanium and so on.
