CNC Routing Machine With 4 Spindles

CNC Routing Machine With 4 Spindles

  • Highlight

    3 axis circuit board maker machine

    ,

    sMT circuit board maker machine

    ,

    CNC smt router machine

CNC Routing Machine With 4 Spindles

Used Four Head Marble CNC Machine


Product Details

BTF6070GS*4

CNC MULTI-STATION PCB DRILLING ROUTING MACHINE/SPECIAL FOR ALUMINIUM

Z Axis Quantity:2

Spindle Quantity:4

Motor Driver:Servo System

Controller:Taiwan Delta

X Y Axis Speed:30m/min

Positioning Accuracy:0.02mm/300mm

Repeatability Accuracy:0.01mm/300mm

Spindle Speed:60000r/min

Effective Stroke:600mm*700mm

Power:AC220V/50HZ /7000W

Air Compression Requirement:0.7MPa-0.8MPa, 600L/min

Environment Size:3.76M*1.78M*1.7M

Machine Weight:6000KG Marble


CNC Routing Machine With 4 Spindles 0


CNC Routing Machine With 4 Spindles 1


CNC Routing Machine With 4 Spindles 2


Our Service:
Terrene offers a one-stop service for customers overseas who need someone trustworthy to help them to search, purchase and integrate the goods they want. Terrene can save you plenty of time and energy, minimize the purchasing cost and offer the right products you need. This high efficient working way will promote your business development greatly.

Terrene follows closely with PCB-related techniques and industrial development figures, continuously optimize and develops new products, and helps the enterprises to have superior services and best investment rewords.

Terrence will offer enterprises the best products, the best whole-set services, with the best reputations. Terrene is willing to be your reliable long-term partner.
